Product Summary

The 4n25 is a general purpose 6-PIN phototransistor optocoupler. It consists of a gallium arsenide infrared emitting diode driving a silicon phototransistor in a 6-pin dual in-line package.

Parametrics

4n25 absolute maximum ratings: (1)Storage Temperature:-55℃ to +150℃; (2)Operating Temperature:-55℃ to +100℃; (3)Wave solder temperature:260℃ for 10 sec; (4)Collector-Emitter Voltage:30 V; (5)Collector-Base Voltage:70 V; (6)Emitter-Collector Voltage:7V; (7)Reverse Input Voltage:6V; (8)Forward Current - Peak (300μs, 2% Duty Cycle):3A.

Features

4n25 features: (1)Also available in white package by specifying -M suffix, eg. 4N25-M; (2)UL recognized (File # E90700); (3)VDE recognized (File # 94766):Add option V for white package(e.g., 4N25V-M),Add option 300 for black package (e.g.,4N25.300).
