Product Summary

The ad654 is a monolithic V/F converter. It consists of an input amplifier, a precision oscillator system, and a high current output stage.

Parametrics

ad654 absolute maximum ratings: (1)Total Supply Voltage +VS to –VS:36 V; (2)Maximum Input Voltage(Pins 3, 4) to –VS :–300 mV to +VS; (3)Maximum Output Current:Instantaneous:50 mA, Sustained:25mA; (4)Logic Common to –VS:–500 mV to (+VS –4); (5)Storage Temperature Range:–65℃ to +150℃.

Features

ad654 features: (1)Low Cost; (2)Single or Dual Supply, 5 V to 36 V, ±5 V to ±18 V; (3)Full-Scale Frequency Up to 500 kHz; (4)Minimum Number of External Components Needed; (5)Versatile Input Amplifier; (6)Positive or Negative Voltage Modes; (7)Negative Current Mode; (8)High Input Impedance, Low Drift; (9)Low Power: 2.0 mA Quiescent Current; (10)Low Offset: 1 mV.
